Straight Blade Flanged Outlet, NEMA 6-15, 15A 250VAC
Straight Blade Flanged Outlet, NEMA 6-15, 15A 250VAC
Straight Blade Flanged Outlet, NEMA 6-15, 15A 250VAC
Straight Blade Flanged Outlet, NEMA 6-15, 15A 250VAC
Straight Blade Flanged Outlet, NEMA 6-15, 15A 250VAC
Straight Blade Flanged Outlet, NEMA 6-15, 15A 250VAC

Straight Blade Flanged Outlet, NEMA 6-15, 15A 250VAC

SKU: 66224 Category:

• Industrial grade flanged outlet designed for maximum durability; NEMA 6-15

• 15 Amp, 250VAC; 2 pole, 3 wire; only accepts #14 AWG solid copper wire

• Made of reinforced Polycarbonate Thermoplastic (PCT), thermoplastic polyester (PBT), and nylon to protect against abrasions, impacts, and chemicals; solid brass blades for improved conductivity

• Ideal for use in both commercial and industrial applications, such as generators, engines, RVs, trailers & trucks

• Terminals marked for identification; NEMA configuration and device rating clearly marked for easy identification; 1-year warranty; UL Listed

Straight Blade Flanged Outlet, NEMA 6-15, 15A 250VAC

ENERLITES’ NEMA devices are designed to provide safe and reliable connections between equipment loads and power sources. The 66224-W, NEMA 6-15 is a straight blade, flanged outlet designed for commercial and industrial applications. This device is crafted with high-quality materials to ensure safe and effective usage. The flanged outlet features an insulated housing made with PBT, nylon, and Polycarbonate Thermoplastic (PCT). The PCT construction offers high resistance to heat, impacts, and chemicals for long-term use in physically demanding applications. All terminals on this 15A NEMA connector are clearly marked for easy identification and fast wiring. The NEMA configuration and device rating are also stamped clearly on the device for easy field identification. This flanged outlet is designed to be used with ENERLITES 66223-W straight blade flanged inlet. This product is UL-listed and includes a one-year warranty.

Technical Specifications

Power Rating 15 Amp, 250VAC
Style NEMA 6-15
Special Features only accepts #14 AWG solid copper wire
Wiring 3 wire
Certifications & Compliance 1-year warranty; UL Listed
Material Polycarbonate Thermoplastic (PCT), thermoplastic polyester (PBT), and nylon
Weight 2.8 oz
Dimensions 6.5 × 2 × 6.5 in
